Operating Basics
2Ć10
MTG100 & MTG300 MPEG Generator User Manual
Knob icon
Selected pullĆdown menu
Command
list
Figure 2Ć6: Example of a displayed pullĆdown menu
When a pull-down menu is displayed, the knob icon is displayed at the upper-
right side of the command list. The knob icon represents the capability of the
rotary knob to move the highlighting (selecting) bar through the command list.
You can also move through the command list using the up and down arrow
buttons. Press the left control button or the OK bezel button to execute the
highlighted command.
Display States of the PullĆdown Menu Commands. The pull-down menu commands
can have the following two display states as shown in Figure 2-7:
H A command followed by “...” represents that a corresponding dialog box will
open after you execute the command.
H A command preceded by a check mark (n) represents the selected command
in a command list subsection. You can select only one command at a time in
a subsection, which is represented by a separation line in the command list.
