Appendix C: Using the ReMux Application
CĆ16
MTG100 & MTG300 MPEG Generator User Manual
Creating a Transport Stream of MĆTMCC Structure.
12. Select Execute in the ReMux pull-down menu or click the " (Execute)
button to open the Save As... dialog box.
13. In the dialog box, specify a file name, and then click the Save button.
If the number of slots of the transport stream of M-TMCC structure you are
going to create is less than 48, a dummy transport stream(s) is(are) inserted
so that the number of slots reached to 48. The transport stream thus inserted
has the ID value set in the OPTION dialog box (See Figure C-4 on page
C-7) and TS8PSK is used as the modulation system.
Multiplexing Transport Streams of MĆTMCC Structure with Different TMCC
Information.
In the ReMux to M-TMCC TS from S-TMCC TS mode, you can multiplex a
transport stream of M-TMCC structure with a transport stream of M-TMCC
structure having different TMCC information.
14. Click the TMCC icon.
15. Select the Add command from the Edit pull-down menu or click the +
(Add) button on the toolbar to open the Add TMCC dialog box as shown in
Figure C-12.
Figure CĆ12: Add TMCC dialog box
In this dialog box, you can specify the transport stream to which the new TMCC
information is inserted if more than one transport stream is multiplexed.
The following illustration shows the positional relationship of TMCC informa-
tion and the transport stream to be inserted to the transport streams already
multiplexed.
