Hierarchy Display
MTG100 & MTG300 MPEG Generator User Manual
3Ć35
Table 3Ć31: Transport stream icon text descriptions (Cont.)
Parameter Description
Consistency error
included
This message is displayed in red when the PID in the PSI or table_id
has no consistency. For ARIB, DVB, or ATSC formats, this error is
displayed when PIDs reserved by the standards are not used properly.
Multi PSI version
included
This message is displayed in red when more than one version of the
PAT or PMT resides in the transport stream.
Table 3Ć32: Transport stream icon Bezel menucommands (MTG300 only)
Command Description
Stress TS Head... Changes the status in all of the packet headers of the transport stream.
When you select this menu item, the TS Head Stress dialog box
appears. Refer to TS Head Stress Dialog Box on page3Ć36 for more
information.
Start/End Packet... Changes the start and end packet of the transport stream.
When you select this menu item, the Start/End Packet dialog box
appears. Refer to Start/End Packet Dialog Box on page3Ć38 for more
information.
Random Error... Inserts random errors into the transport stream.
When you select this menu item, the Random Error Stress dialog box
appears. Refer to Random Error Stress Dialog Box on page3Ć39 for
moreinformation.
Reset Insert & Stress Cancels all of the insertion and stress functions for the transport stream.
When you press this bezel button, a confirmation message box appears
for you to confirm the operation. Press the OK bezel button to execute
the operation or press the Cancel bezel button to cancel the operation
and return to the state prior to selecting this menu item.
