Hierarchy Display
MTG100 & MTG300 MPEG Generator User Manual
3Ć33
Table 3Ć29: Icons specific to ISDBĆS and Non TS format
Icon Element type
БББББББББББББББББББББ
Б БББББББББББББББББББ Б
Б БББББББББББББББББББ Б
БББББББББББББББББББББ
S-TMCC
Transport stream to which TMCC information is inserted into 8 bytes in its
ReedĆSolomon area (16 bytes).
БББББББББББББББББББББ
Б БББББББББББББББББББ Б
Б БББББББББББББББББББ Б
БББББББББББББББББББББ
MĆTMCC
Transport stream to which TMCC information is inserted into its sync byte area,
and having super frame structure.
БББББББББББББББББББББ
Б БББББББББББББББББББ Б
БББББББББББББББББББББ
Transport Stream (TS)
Transport stream composing the SĆTMCC or MĆTMCC.
БББББББББББББББББББББ
Б БББББББББББББББББББ Б
Б БББББББББББББББББББ Б
БББББББББББББББББББББ
Non TS
Data stream other than transport stream format, which is downloaded in Non TS
format.
Table 3Ć30: Icons specific to userĆinserted data 1
Icon Element type
INS_SI
The service information insertion file inserted by the MPEG generator into the
transport stream.
INS_TS
A transport stream insertion file inserted by the MPEG generator into the
transport stream.
INS_TDT or INS_TOT
A TDT or TOT inserted by the MPEG generator into the transport stream.
INS_STT
An STT inserted by the MPEG generator into the transport stream.
1 These Icons's background are colored blue.
