Hierarchy Display
MTG100 & MTG300 MPEG Generator User Manual
3Ć37
Table 3Ć33: TS Head Stress dialog box parameters
Parameter Description
SyncByte The setĆup sync_byte value (0 to 255) is replaced at every setĆup packet
interval (0 to 65535) by the setĆup number of packets (1 to 65535).
Transport Error
Indicator
The setĆup transport_error_indicator value (0 or 1) is replaced at every
setĆup packet interval (0 to 65535) by the setĆup number of packets (1 to
65535).
Payload Start
Indicator
The setĆup payload_unit_start_indicator value (0 or 1) is replaced at every
setĆup packet interval (0 to 65535) by the setĆup number of packets (1 to
65535).
Transport Priority The setĆup transport_priority value (0 or 1) is replaced at every setĆup packet
interval (0 to 65535) by the setĆup number of packets (1 to 65535).
PID The setĆup PID value (0 to 8191) is replaced at every setĆup packet interval
(0 to 65535) by the setĆup number of packets (1 to 65535).
Transport ScramĆ
bling Control
The setĆup transport_scrambling_control value (0 to 3) is replaced at every
setĆup packet interval (0 to 65535) by the setĆup number of packets (1 to
65535).
Adaptation Field
Control
The setĆup adaptation_field_control value (0 to 3) is replaced at every setĆup
packet interval (0 to 65535) by the setĆup number of packets (1 to 65535).
CC_Lack The continuity_counter value is deleted from the setĆup value (0 to 15) at
every setĆup interval ( 0 to 65535) by the setĆup number of packets (1 to 15).
CC_Duplicate Out of the setĆup value (0 to 15), continuity_counter value is copied at every
setĆup interval (0 to 65535) by the setĆup number of packets.
Table 3Ć34: Bezel menu commands for the TS Head Stress dialog box
Command Description
Effect Check Enables the selected test. A check mark (n) appears by the enabled test.
Abort When the Count box of the selected test is set to 0, abort the execution of
the test.
Default Resets all of the dialog box settings back to the factory default settings.
Exit Menu Cancels any setting changes and closes the dialog box.
Apply Applies the selected test to the transport stream. The stress tests activated
from this dialog box are momentary. Any transport stream setting changes
applied by a test revert to their prior state when the test is completed.
