MTG100 & MTG300 MPEG Generator User Manual
3Ć99
File Operations
This section explains the following file operations used in the MPEG generator:
H Creating a new folder
H Copying a file
H Deleting a file or folder
H Renaming a file name or folder name
Refer to Preset File beginning on page 3-95, how to save and load a preset file.
Creating a new folder
NOTE. You cannot create a new folder (subdirectory) in the same hierarchy as
that of the insert, preset, and ts folders (directories) on the main drive (hard disk
drive).
Perform the following procedures to create a new folder (subdirectory):
1. Select New folder... from FILE pull-down menu, and then press the OK
bezel button. This opens the Input new folder name dialog box shown in
Figure 3-37.
Figure 3Ć37: Input new folder name dialog box
