Hierarchy Display
3Ć72
MTG100 & MTG300 MPEG Generator User Manual
Table 3-92 describes the text information and Table 3-93 describes the Bezel
menu commands for the Terrestrial Virtual Channel Table (TVCT), Cable Virtual
Channel Table (CVCT), Rating Region Table (RRT), Event Information Table
(EIT), Channel Extended Text Table (CETT), and Event Extended Text Table
(EETT) icons.
Table 3Ć92: TVCT, CVCT, RRT, EIT, CETT, and EETT icon text descriptions
Parameter Description
PID Shows the PID value of the TVCT, CVCT, RRT, EIT, CETT, or EETT.
Table ID Shows the table_id value of the TVCT, CVCT, RRT, EIT, CETT, or EETT.
Table Type Shows the table_type value of the TVCT, CVCT, RRT, EIT, CETT, or
EETT.
Interval Shows the average period of the packets when the
payload_unit_start_indicator value is set to 1.
Table 3Ć93: TVCT, CVCT, RRT, EIT, CETT, and EETT icon Bezel menu commands
(MTG300 only)
Command Description
Stress TS Head... Changes the status of the packet header in the packet containing the
TVCT, CVCT, RRT, EIT, CETT, or EETT.
When you select this menu item, the TS Head Stress dialog box
appears. Refer to TS Head Stress Dialog Box on page 3Ć36 for more
information.
Stress SI... Changes the status of the section header in the TVCT, CVCT, RRT, EIT,
CETT, or EETT.
When you select this menu item, the Stress SI dialog box appears.
Refer to Stress SI Dialog Box on page 3Ć61 for more information.
Reset Replace Cancels the data replacement activated by the Replace Section...
command and restores the original data.
TVCT, CVCT, RRT, EIT,
CETT, and EETT Icons
