Hierarchy Display
3Ć34
MTG100 & MTG300 MPEG Generator User Manual
Icon Text and Bezel Menu Commands
To the right of each icon, the MPEG generator displays text that describes each
transport stream component. The text associated with an icon will change color
to indicate the following conditions:
H Red text indicates that the selected transport stream is not suited for
outputting with the Auto Update loop mode. The No Update loop mode is
recommended for outputting it.
H Orange text indicates that the parameters of the component have been
changed from its default value.
H Green text indicates that the component has been replaced with the specified
section file.
When you use the Icon cursor to select a transport stream component, the Bezel
menu displays commands that apply only to the selected component (MTG300
only). This subsection describes the text information and available Bezel menu
commands for each icon type.
NOTE. Only the MTG300 MPEG generator can access the Bezel menu com-
mands for the selected transport stream icon. The output loop mode must be set
to Stress for all of the available Bezel menu commands to appear. Refer to
Output Loop Modes on page 2-15 for more information.
Table 3-31 describes the text information and Table 3-32 describes the Bezel
menu commands for the Transport Stream (TS) icon.
Table 3Ć31: Transport stream icon text descriptions
Parameter Description
TSĂID Shows the ID number for the transport stream.
Filename Shows the file name and path of the transport stream.
Output Rate Shows the output rate of the transport stream.
Format Shows the packetĆsize format of the transport stream in bytes (188, 204,
or 208).
Total Packet Shows the total number of packets in the transport stream.
Start Packet Shows the number of the start packet in the transport stream.
End Packet Shows the number of the end packet in the transport stream.
Transport Stream (TS)
Icon
