Hierarchy Display
MTG100 & MTG300 MPEG Generator User Manual
3Ć63
Table 3-76 describes the text information and Table 3-77 describes the Bezel
menu commands for the GHOST icon.
Table 3Ć76: GHOST icon text descriptions
Parameter
Description
PID
Shows the PID value of the GHOST.
Packet Rate
Shows the average output rate of the packet.
Table 3Ć77: GHOST icon Bezel menu commands(MTG300 only)
Command
Description
Stress TS Head...
Changes the status of the packet header in the packet containing the
GHOST.
When you select this menu item, the TS Head Stress dialog box
appears. Refer to TS Head Stress Dialog Box on page 3Ć36 for more
information.
Del Packet
Toggles the Delete Packet function between Inactive and Active.
Inactive: Cancels the delete packet operation.
Active: Deletes the selected itemfromthe transport stream. If other
items with the same PID value as the selected item exist in the transport
streamand they are contained in one packet, they are also deleted from
the transport stream(except for the PCR). When the itemis deleted, the
iteminformation is shaded in the hierarchy display.
GHOST Icon
