Hierarchy Display
3Ć44
MTG100 & MTG300 MPEG Generator User Manual
Table 3Ć43: Bezel menu commands for the Replace Setup dialog box
Command Description
Default Resets all of the dialog box settings back to the factory default settings.
Cancel Cancels any setting changes and closes the dialog box.
Apply Enables all setting changes. When you apply setting changes, data output
fromthe MPEG generator is stopped. You must restart the MPEG generator
output for the setting changes to appear.
Table 3-44 describes the text information and Table 3-45 describes the Bezel
menu commands for the Transport Stream Description Table (TSDT) icon.
Table 3Ć44: TSDT icon text descriptions
Parameter Description
PID Shows the PID value of the TSDT.
Table ID Shows the table_id value of the TSDT.
Interval Shows the period of the TSDT.
Table 3Ć45: TSDT icon Bezel menu commands (MTG300 only)
Command Description
Stress TS Head... Changes the status of the packet header in the packet containing the
TDST.
When you select this menu item, the TS Head Stress dialog box
appears. Refer to TS Head Stress Dialog Box on page 3Ć36 for more
information.
Reset Replace Cancels the data replacement activated by the Replace Section...
command and restores the original data.
Transport Stream
Description Table (TSDT)
Icon
