Appendix B: Using MTG Comm + for File Transfers
MTG100 & MTG300 MPEG Generator User Manual
BĆ15
Table BĆ4: User Check dialog boxparameters (Cont.)
Parameter Description
Data Rate Sets the default clock rate used by the MPEG generator to playback the
stream. The MTG Comm + application analyzes the selected stream and
automatically approximates the data rate. You can enter values in the
fraction fields to provide greater clock accuracy.
You can use the packet size box to have the MPEG generator playback
the transport stream file with a specified packet size that is different than
the original file.
After you enter values in the Data Rate fields, do not press the keyboard
Enter key. Refer to the Caution note on page BĆ8.
Private Section
Definition File
Specifies the file describingthe PID and table_id values of the
private_section. If the selected transport stream file contains the transport
stream packet with the PID and table_id value described in the private
section definition file, the packet appears in the hierarchy display as a
PRI icon.
Use the followingformat to describe the private section definition file:
PID, table_id
The followingis an example of the private section definition file in the
hexadecimal value:
0x1000,0x80
0xaa,0x55
.
.
You can directly describe the file name in the text box. When you click the
Edit button, you can edit the file usingthe text editor specified by the
Options command of the Utility pullĆdown menu. When you click the ..."
button, the Open File dialogbox opens where you can select another
private section definition file.
