Pull-down Menus
3Ć10
MTG100 & MTG300 MPEG Generator User Manual
Table 3Ć7: CONFIG pullĆdown menu commands (Cont.)
Command Description
TDT/TOT/STT
Update
Sets whether or not the timing values of the TDT/TOT/STT are updated
in the Auto Update and Stress output loop mode. You can select ON or
OFF. When you set it to OFF, the TDT..., TOT..., and STT... bezelmenus
are disabled.
Auto play on power
up
Sets whether or not the transport stream is automatically output using
the last powerĆdown settings when you turn the MPEG generator on.
You can select ON or OFF. If you set it to ON, take care of the output
level setting used when the he MPEG generator was last turned off and
the input level of the instrument (device) currently connected to the
MPEG generator.
Start/End Packet Dialog Box. When you select the Start/End Packet... command
from the Bezel menu on your MTG300 MPEG generator, the Start/End Packet
dialog box appears as shown in Figure 3-14. Use the arrow buttons to highlight
the desired parameter, and the use the rotary knob or hexadecimal keypad to set
the value. Press the Apply bezel button to apply changes.
Table 3-8 describes the Start/End Packet dialog box parameters and Table 3-9
describes the Bezel menu commands associated with the dialog box.
Figure 3Ć3: Start/End Packet dialog box
Table 3Ć8: Start/End Packet dialog box parameters
Parameter Description
Finename Shows the directory path and file name of the transport stream.
TS ID Shows the TS ID of the transport stream.
TotalPacket Shows the totalnumber of packets in the transport stream.
