92 2 Installation and Specifications
2
.3
S
o
ft
wa
re
s
e
tu
p Graph points
Graph Pnts (Points) is the maximum number of points that will be
plotted on graphs of subgroups for the specified part.
To specify Graph Pnts:
U Highlight the Graph Pnts field
U Enter the maximum number points to be graphed
U Press the ENTER key
Next record ID
Record ID numbers are displayed on graphs and can be included in
printed reports and transmitted data.
Normally, the Next Record ID field starts at 1 and is automatically
incremented by the system each time a new record is stored.
However, the Next Record ID field can be set to any value by the user
to restart a new database at a specified record number, or for a variety
of other reasons. Enter the Next Record ID to restart the database at
a new number. Entering 999,999,999 will prevent any data from being
recorded in the database.
To specify the Next Record ID:
U Highlight the Next Record ID field
U Use the numeric keypad to enter the desired ID for the next record
U Press the ENTER key
Dimension
To specify the dimension used for the current SPC settings:
U Highlight the Dimension field
U Press the DEC or INC soft key until the desired dimension is
displayed in the field
U Press the ENTER key
When there are fewer graph points specified than
subgroups, the resulting dimension graphs might need to
be scrolled to view all the subgroup data. Refer to Chapter
1: Operation for details regarding viewing and scrolling
graphs.
