ND 2100G GAGE-CHEK 193
2.4 F
o
rm
ulas
Advanced functions include +-*/, Math and Other menus:
„ Comma: Separate arguments for a single formula
„ Semicolon: Separate formulas for a single dimension
„ Greater than (>): Logical test criterion
„ Greater than or equal to (>=): Logical test criterion
„ Less than (<): Logical test criterion
„ Less than or equal to (<=): Logical test criterion
„ Equal to (==): Logical test criterion
„ Not equal to (!=): Logical test criterion
„ AND (&&): Logical test condition
„ OR (||): Logical test condition
„ RANGE (--): Inclusive range of values between two specified points
„ Minimum value (min): Return the minimum value from a list
„ Maximum value (max): Return the maximum value from a list
„ Modulo (mod): Return the remainder value from a division operation
„ If: Logical true/false test that controls decisions and process flow
„ Case: Logical range test that controls decisions and process flow
„ Sequence (seq): Control process to follow predetermined sequence
of steps
„ Trip: Automate process or SPC entry based on channel input or
dimension levels
„ Dynamic minimum (dmn): Return the minimum sampled input value
„ Dynamic maximum (dmx): Return the maximum sampled input
value
„ Dynamic average (davg): Return the average sampled input value
„ Dynamic median (dmd): Return the median sampled input value
„ Fail: Return logic levels for dimension tolerance pass/fail
„ Xtra: An additional menu of functions is accessed through the Xtra
item and discussed later in this chapter
