p Enter new station values
The following steps enter standard and observed values across the
entire range of measurement.
The Station 0 data is used as the reference for all subsequent SLEC
segment measurements and is derived from the standard’s zero
reference. Station 0 Standard and Observed field data must be
identical or entered as zeros to initiate the standard’s reference
position.
To enter new station values:
U Highlight the Standard field.
U Use the numeric keypad to enter 0
U Press the ENTER key. The Observed field is highlighted.
U Use the numeric keypad to enter 0
U Press the ENTER key
Now that the Station 0 reference data is entered into Standard and
Observed fields, subsequent observed values can be measured and
entered.
U Highlight the Station field
U Press the INC soft key to enter the next station number
U Highlight the Standard field
U Use the numeric keypad to enter the value marked on the standard
part
U Press the ENTER key to enter the value. The Observed field is
highlighted.
U Position the probe against the surface of the standard
U Press the TEACH soft key. The appropriate measured value will be
displayed in the Observed field.
U Press the ENTER key to enter the value
U Repeat these steps to enter Standard and Observed values across
the entire encoder range
Clear all
Datums Cycle Power &
Set Machine 0 Clear Old
Values &
Disable SLEC Enter
Machine 0
Offset Enter New
Station
Values Enable SLEC
