Reviewing measurements
Measurement results can be reviewed in graphs or in data tables using
the screens described earlier in this chapter. Please refer to the
descriptions of Views on page 28.
Printing reports or sending results to a computer
Measurement data can be printed or transmitted to a computer. The
report and data transmission formats are prepared in the Header,
Report, Send, Parallel and RS-232 setup screens described in Chapter
2: Installation, Setup and Specifications.
Printing reports
Reports of current dimension values, stored measurement results or
ND 2100G setup parameters can be printed by displaying the desired
screen and pressing the PRINT key. In some cases, the user will be
prompted to provide additional information.
Select Part Establish a
Measurement
Reference Conduct a
Measurement Review
Measurement
Data Report or Send
Results
Select Part Establish a
Measurement
Reference Conduct a
Measurement Review
Measurement
Data Report or Send
Results
