ND 2100G GAGE-CHEK 231
2.4 F
o
rm
ulas
Din function syntax
A = Din(Pin number)
The logic level at a single Din pin is assigned to a dimension as a
numeric 1 or 0.
A = Din(Range of pin numbers)
The decimal equivalent of the binary values from a range of pins are
assigned to a dimension as a numeric value.
Example 1:
A = Din(3)
A = 1
When Din(3) = logic level 1
Example 2:
A = Din(3--5)
A = 20
When: Din(3) = logic level 1
Din(4) = logic level 0
Din(5) = logic level 1
Din Din(5) Din(4) Din(3) Din(2) Din(1)
Din logic level 1 0 1 0 1
Decimal equiv. 16 0 4 0 1
Specified range
