270 2 Installation and Specifications
2.5 Specifications
2.5 Specifications
Specifications
Channel inputs „ 1, 4 or 8 single-input channels
„ Up to 16 networked RS-232 input channels
„ Combinations of single-input channels and networked RS-232 input channels for a total of up
to 16 channels
Display Color LCD
„ 5.7” (14.48 cm)
„ 0.50” (1.27 cm) display digit size
„ 0.000004” (0.00001 mm) Resolution
Error compensation Linear (LEC), segmented linear (SLEC)
Data interfaces Serial interfaces
„ RS-232-C
„ USB 2.0 Type A Full-speed
Optional accessories „ Remote foot switch
„ Remote keypad
„ ND 2100G Protective cover
„ QUADRA-CHEK Wedge communication software
Main power input 100 Vac to 240 Vac; 50 to 60 Hz
Line fuse 1.6 Amp, 250 V slow blow; 5 X 20 mm
Output relay „ Switching voltage 100V Max DC
„ Switching current 0.25A Max DC
„ Carry current 0.5A Max DC
„ Contact rating 3W Max DC
ENC testing „ EN61326: 1998 EMC for electrical equipment for measurement, control and laboratory use
„ EN61010: Safety requirements for electrical equipment for measurement, control and
laboratory use
Installation category II
Environmental „ Temperature: 32 °F to 113 °F (0 °C to 45 °C) non-condensing
„ Relative air humidity: 90%
„ Altitude: 6562 feet (2000 meters)
Enclosure Benchtop; cast-metal enclosure
