234 2 Installation and Specifications
2.4 F
o
rm
ulas
Dout function syntax
Hn = Dout(Pin number/range of pins, state, delay)
Where: Pin number/range of pins specifies which output pin or
pins are used.
State is the logic level to output to the specified pins.
Delay is the output period in seconds - if a delay is not
included, the output is continuous.
Example 1:
H1 = Dout(3,1)
H1 = Sets Dout pin 3 to a logical 1 continuously
Example 2:
H1 = Dout(3--5,1,5sec)
H1 = Sets Dout pins 3 through 5 to a logical 1 for 5 seconds, then
to zero
