ND 2100G GAGE-CHEK 149
2
.3
S
o
ft
wa
re
s
e
tu
p Graph...
The Graph... function selects the line graph view of stored records.
Histo...
The Histo... function selects the histogram graph view of stored
records for display on the DRO screen.
Hold
This toggle function holds (freezes) or releases the current value
displayed on the LCD for this dimension.
in/mm
Toggles between the display of dimension values between inches and
mm.
Master
Displays the Master screen for calibrating or presetting inputs.
Part No.
The part number, selected by the user during Hot Key setup, becomes
the current part when the key is pressed.
Part?
Displays a pop-up screen that allows the user to specify a new part
number.
Preset
Presets this dimension’s datum.
Pressure
The Pressure function cycles through the display of units of pressure
measurement as the hot key is repeatedly pressed. When the
Pressure function is assigned to a soft key, the unit of pressure
measurement will be displayed on the LCD above the soft key. When
the Pressure function is assigned to something other than a soft key,
the Show DRO Units function must be enabled in the Display setup
screen to display the units of measure on the DRO.
Units of pressure measurement include:
„ ATM: Atmospheres
„ Bar: Bars
„ Pa: Pascals
„ PSI: Pounds per square inch
