ND 2100G GAGE-CHEK 221
2.4 F
o
rm
ulas
„ Recall: Recalls dimension values that were specified the last time
the Preset function was used
„ Relay: Operate dry-contact relay outputs
„ Remark: Adds a comment to a formula, but has no effect on values
or operation
„ Report: Print report on the parallel or serial port
„ Reset dynamic (RsetDyn): Clear dmn, dmx, HwDmn and HwDmx
sampled channel input values in preparation for new samples
„ Scan: Collects all channel data at the maximum rate
„ Send: Transmit specified dimension(s) to an output port
„ Send message (SendMsg): Transmit text or ASCII codes to the RS-
232 port
„ Send record (SendRec): Transmit a specified dimension record(s) to
an output port
„ SetColor: Sets the color of a specified dimension displayed on the
DRO
„ Set trigger (SetTrig): Part of the OnEvent function. Sets a user
defined event trigger.
„ Setup: Performs a variety of setup functions for the specified
dimension
„ Time: Return elapsed time since startup or the amount a formula
term has changed over an elapsed time
„ TimeString (TimeStr): Returns the current system time
„ Variable (Var): Returns or initializes the value of a local variable
available for individual parts
„ XLatch (Optional): Return a channel input value when an external
edge is detected
