198 2 Installation and Specifications
2.4 F
o
rm
ulas
Din
Din ranges can only be specified for the data input pins of the parallel
connector.
Dout
Dout ranges can only be specified for the data output pins of the
parallel connector.
Din syntax
Din (1--n)
Specifies Din (1) through Din (n).
Example:
If(Din(1--4)>0,SendRec,0)
If any Din in the range Din (1) through Din (4) is greater than zero,
send our record, otherwise do nothing.
Dout syntax
Dout (1--n)
Specifies Dout (1) through Dout (n).
Example:
Dout(1--4,1)
Sets all Dout in the Range Dout(1) through Dout(4) to a logic 1.
