ND 2100G GAGE-CHEK 133
2
.3
S
o
ft
wa
re
s
e
tu
p Record content
The records transmitted can include a range specified by the user;
records not yet transmitted (New), all records in the database or only
the selected record.
To specify the records to be sent:
U Highlight the Recs To Send field
U Press the soft key for the type of records to be sent
U Press the ENTER key
Min Dimen Size
Dimension data can be transmitted over the RS-232 connection with
or without formatting placeholders.
To specify Min Dimen size:
U Highlight the Min Dimen Size field
U Press the LARGEST or SMALLEST soft key
U Press the ENTER key
Type Description
Range The user will be prompted to specify the number of
records to transmit.
New Only records that have not yet been printed will be
sent.
All All records in the database will be transmitted.
Selected The highlighted record will be transmitted.
Prompt The user will be prompted to select records to be
transmitted.
Option Description Example
Largest Sends data spaces for a sign
character, 8 digits and a decimal
point. | | | | | |8|.|2|1|7|
Smallest sends only the required 5 data
spaces. |8|.|2|1|7|
