User’s Manual of NS3550-8T-2S
85
Figure 4-4-2: Port Statistics Overview Page Screenshot
The displayed counters are:
Object Description

Port The logical port for the settings contained in the same row.

Packets The number of received and transmitted packets per port.

Bytes The number of received and transmitted bytes per port.

Errors The number of frames received in error and the number of incomplete
transmissions per port.

Drops The number of frames discarded due to ingress or egress congestion.
 Filtered The number of received frames filtered by the forwarding process.
Buttons
: Click to refresh the page immediately.
: Clears the counters for all ports.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
