User’s Manual of NS3550-8T-2S
104
25. Q-in-Q Mode Sets the Managed Switch to QinQ mode, and allows the QinQ tunnel port to be
configured. The default is for the Managed Switch to function in Disable mode.

Disable : The port operates in its normal VLAN mode. (This is the
default.)

MAN Port : Configures IEEE 802.1Q tunneling (QinQ) for an uplink
port to another device within the service provider network.

Customer Port : Configures IEEE 802.1Q tunneling (QinQ) for a client
access port to segregate and preserve customer VLAN IDs for traffic
crossing the service provider network.
Set Out layer VLAN tag
ether type The Tag Protocol Identifier (TPID) specifies the ethertype of incoming packets on
a tunnel access port.

802.1Q Tag : 8100

vMAN Tag : 88A8
Default : 802.1Q Tag
The port must be a member of the same VLAN as the Port VLAN ID.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
