4.17.10 RMON Statistics Configuration
Configure RMON Statistics table on this page. The entry index key is ID; screen in Figure 4-17-10 appears.
Figure 4-17-10: RMON Statistics Configuration Page screenshot
The page includes the following fields:
Object Description
 Delete Check to delete the entry. It will be deleted during the next save.
 ID Indicates the index of the entry. The range is from 1 to 65535.
 Data Source Indicates the port ID which wants to be monitored. If in stacking switch, the value
must add 1000*(switch ID-1), for example, if the port is switch 3 port 5, the value
is 2005
Buttons
: Click to add a new community entry.
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
