User’s Manual of NS3550-8T-2S
168
The page includes the following fields:
Object Description
 Mode Controls the tag remarking mode for this port.

Classified : Use classified PCP/DEI values.

Default : Use default PCP/DEI values.

Mapped : Use mapped versions of QoS class and DP level.
 PCP/DEI Configuration Controls the default PCP and DEI values used when the mode is set to Default.

(QoS class, DP level)
to (PCP, DEI) Mapping
Controls the mapping of the classified (QoS class, DP level) to (PCP, DEI) values
when the mode is set to Mapped.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
: Click to undo any changes made locally and return to the previous page.
