User’s Manual of NS3550-8T-2S
48
Figure 4-2-2: IP Configuration Page Screenshot
The current column is used to show the active IP configuration.
Object Description

DHCP Client
Enable the DHCP client by checking this box. If DHCP fails and the configured IP
address is zero, DHCP will retry. If DHCP server does not respond around 35 seconds
and the configured IP address is non-zero, DHCP will stop and the configured IP
settings will be used. The DHCP client will announce the configured System Name as
host name to provide DNS lookup.

IP Address Provide the IP address of this switch in dotted decimal notation.

IP Mask
Provide the IP mask of this switch dotted decimal notation.

IP Router
Provide the IP address of the router in dotted decimal notation.
 VLAN ID Provide the managed VLAN ID. The allowed range is 1 through 4095.
 DNS Server Provide the IP address of the DNS Server in dotted decimal notation.
 DNS Proxy When DNS proxy is enabled, DUT will relay DNS requests to the current configured
DNS server on DUT, and reply as a DNS resolver to the client device on the network.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
: Click to renew DHCP Client. This button is only available if DHCP Client is enabled.
4.2.3 IPv6 Configuration
Configure the switch-managed IPv6 information on this page.
The Configured column is used to view or change the IPv6 configuration. The Current column is used to show the active IPv6
configuration. The screen in
Figure 4-2-3 appears.
