180
4.9.14 QoS Statistics
This page provides statistics for the different queues for all switch ports. The QoS Statistics screen in Figure 4-9-17 appears.
Figure 4-9-17: Queuing Counters Page Screenshot
The page includes the following fields:
Object Description

Port
The logical port for the settings contained in the same row.

Q0 ~ Q7
There are 8 QoS queues per port. Q0 is the lowest priority queue.
 Rx/Tx The number of received and transmitted packets per queue.
Buttons
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the page immediate
: Clears the counters for all ports.
