User’s Manual of NS3550-8T-2S
58
 Receive Missing
Circuit ID
The number of packets received with the Circuit ID option missing.
 Receive Missing
Remote ID
The number of packets received with the Remote ID option missing.
 Receive Bad Circuit ID The number of packets whose Circuit ID option did not match known circuit ID.
 Receive Bad Remote
ID
The number of packets whose Remote ID option did not match known Remote
ID.
Client Statistics
Object Description
 Transmit to Client The number of relayed packets from server to client.
 Transmit Error The number of packets that resulted in error while being sent to servers.
 Receive from Client The number of received packets from server.
 Receive Agent Option The number of received packets with relay agent information option.
 Replace Agent Option The number of packets which were replaced with relay agent information option.
 Keep Agent Optin The number of packets whose relay agent information was retained.
 Drop Agent Option The number of packets that was dropped which were received with relay agent
information.
Buttons
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the page immediately.
: Clear all statistics.
