User’s Manual of NS3550-8T-2S
77
Object Description
10. Trap Mode Indicates the SNMP trap mode operation. Possible modes are:

Enabled : Enable SNMP trap mode operation.

Disabled : Disable SNMP trap mode operation.
11. Trap Version Indicates the SNMP trap supported version. Possible versions are:

SNMP v1 : Set SNMP trap supported version 1.

SNMP v2c : Set SNMP trap supported version 2c.

SNMP v3 : Set SNMP trap supported version 3.

Trap Community
Indicates the community access string when send SNMP trap packet. The
allowed string length is 0 to 255, and the allowed content is the ASCII characters
from 33 to 126.

Trap Destination
Address
Indicates the SNMP trap destination address. It allow a valid IP address in dotted
decimal notation ('x.y.z.w').
And it also allow a valid hostname. A valid hostname is a string drawn from the
alphabet (A-Za-z), digits (0-9), dot (.), dash (-). Spaces are not allowed, the first
character must be an alpha character, and the first and last characters must not
be a dot or a dash.
 Trap Destination IPv6
Address
Indicates the SNMP trap destination IPv6 address. IPv6 address is in 128-bit
records represented as eight fields of up to four hexadecimal digits with a colon
separating each field (:). For example, 'fe80::215:c5ff:fe03:4dc7'. The symbol '::'
is a special syntax that can be used as a shorthand way of representing multiple
16-bit groups of contiguous zeros; but it can appear only once. It can also
represent a legally valid IPv4 address. For example, '::192.1.2.34'.
12. Trap Authentication
Failure Indicates the SNMP entity is permitted to generate authentication failure traps.
Possible modes are:

Enabled : Enable SNMP trap authentication failure.

Disabled : Disable SNMP trap authentication failure.
13. Trap Link-up and
Link-down
Indicates the SNMP trap link-up and link-down mode operation. Possible modes
are:

Enabled : Enable SNMP trap link-up and link-down mode operation.

Disabled : Disable SNMP trap link-up and link-down mode operation.
14. Trap Inform Mode Indicates the SNMP trap inform mode operation. Possible modes are:

Enabled : Enable SNMP trap inform mode operation.

Disabled : Disable SNMP trap inform mode operation.
 Trap Inform Timeout
(seconds)
Indicates the SNMP trap inform timeout. The allowed range is 0 to 2147.
 Trap Inform Retry
Times
Indicates the SNMP trap informs retry times. The allowed range is 0 to 255.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
