User’s Manual of NS3550-8T-2S
177
0x00 to 0xFF or 'Any', the default value is 'Any'
 Control Address Valid Control Address can vary from 0x00 to 0xFF or 'Any',
the default value is 'Any'
 SNAP PID Valid PID(a.k.a ethernet type) can have value within 0x00-0xFFFF or 'Any',
default value is 'Any'
 IPv4  Protocol IP protocol number: (0-255, TCP or UDP) or 'Any'
 Source IP Specific Source IP address in value/mask format or 'Any'. IP and
Mask are in the format x.y.z.w where x, y, z, and w are decimal numbers
between 0 and 255. When Mask is converted to a 32-bit binary string and
read from left to right, all bits following the first zero must also be zero
DSCP
Diffserv Code Point value(DSCP): It can be specific value, range of
value or 'Any'. DSCP values are in the range 0-63 including BE, CS1-CS7,
EF or AF11-AF43
 IP Fragment IPv4 frame fragmented option: yes|no|any
 Sport Source TCP/UDP port:(0-65535) or 'Any', specific or port range
applicable for IP protocol UDP/TCP
 Dport Destination TCP/UDP port:(0-65535) or 'Any', specific or port range
applicable for IP protocol UDP/TCP
29. IPv6

Protocol IP protocol number: (0-255, TCP or UDP) or 'Any'

Source IP IPv6 source address: (a.b.c.d) or 'Any', 32 LS bits

DSCP Diffserv Code Point value(DSCP): It can be specific value, range of
value or 'Any'. DSCP values are in the range 0-63 including BE, CS1-CS7,
EF or AF11-AF43

Sport Source TCP/UDP port:(0-65535) or 'Any', specific or port range
applicable for IP protocol UDP/TCP

Dport Destination TCP/UDP port:(0-65535) or 'Any', specific or port range
applicable for IP protocol UDP/TCP
30. Action Parameters 
Class QoS class: (0-7) or 'Default'.

DP Valid Drop Precedence Level can be (0-1) or 'Default'.

DSCP Valid DSCP value can be (0-63, BE, CS1-CS7, EF or AF11-AF43) or
'Default'.
'Default' means that the default classified value is not modified by this QCE.
Buttons
: Click to save the configuration and move to main QCL page
: Click to undo any changes made locally and revert to previously saved values
: Return to the previous page without saving the configuration change
4.9.12 QoS Status
This page shows the QCL status by different QCL users. Each row describes the QCE that is defined. It is a conflict if a specific
QCE is not applied to the hardware due to hardware limitations. The maximum number of QCEs is 256 on each switch. The
QoS Control List Status screen in
Figure 4-9-15 appears.
Figure 4-9-15: QoS Control List Status Page Screenshot
The page includes the following fields:
Object Description
 User Indicates the QCL user.
