326

6.5 VLAN Configuration Command

VLAN Configuration

Description:

Show VLAN configuration.


Syntax:

VLAN Configuration []


Parameters:

: Port list or 'all',

(default: All ports)

Example:

Show VLAN status of port1

NS3550-8T-2S:/>vlan configuration 1

VLAN Configuration:
===================


Mode : IEEE 802.1Q
Port PVID IngrFilter FrameType LinkType Q-in-Q Mode Eth type
---- ---- ---------- ---------- -------- ----------- --------
1 1 Disabled All UnTag Disable N/A

VID VLAN Name Ports
---- -------------------------------- -----
1 default 1-10

VID VLAN Name Ports
---- -------------------------------- -----
VLAN forbidden table is empty


VLAV PVID

Description:

Set or show the port VLAN ID.

Syntax:

VLAN PVID [] [|none]


Parameters:

: Port list or 'all', default: All ports

|none

: Port VLAN ID (1-4095) or 'none',

(default: Show port VLAN ID)


Default Setting:

1

Example:

Set PVID2 for port10

NS3550-8T-2S:/>vlan pvid 10 2


VLAN Frame Type

Description:

Set or show the port VLAN frame type.


Syntax:

VLAN FrameType [] [all|tagged]


Parameters:

: Port list or 'all', default: All ports
