194
The page includes the following fields:
Object Description

Port
The logical port for the settings contained in the same row.

Policy ID Select the policy to apply to this port. The allowed values are 1 through 8. The
default value is 1.

Action
Select whether forwarding is permitted ("Permit") or denied ("Deny"). The default
value is "Permit". All means all ports will have one specific setting.

Rate Limiter ID
Select which rate limiter to apply to this port. The allowed values are Disabled
or the values 1 through 15. The default value is "Disabled". All means all ports
will have one specific setting.
 EVC Policer Select whether EVC policer is enabled or disabled. The default value is
"Disabled"
. All means all ports will have one specific setting.
 EVC Policer ID Select which EVC policer ID to apply on this port. The allowed values are
Disabled
or the values 1 through 128.

Port Redirect
Select which port frames are redirected on. The allowed values are Disabled or
a specific port number. The default value is "Disabled". All means all ports will
have one specific setting.
 Mirror Specify the mirror operation of this port. The allowed values are:
Enabled
: Frames received on the port are mirrored.
Disabled : Frames received on the port are not mirrored.
The default value is "Disabled".
All
means all ports will have one specific setting.
 Logging Specify the logging operation of this port. The allowed values are:
Enabled
: Frames received on the port are stored in the System Log.
Disabled : Frames received on the port are not logged.
The default value is "Disabled".
Please note that the System Log memory size and logging rate is limited.
All means all ports will have one specific setting.
 Shutdown Specify the port shut down operation of this port. The allowed values are:
Enabled
: If a frame is received on the port, the port will be disabled.
Disabled : Port shut down is disabled.
The default value is "Disabled".
All
means all ports will have one specific setting.
 State Specify the port state of this port. The allowed values are:
Enabled
: To reopen ports by changing the volatile port configuration of the ACL
user module.
Disabled
: To close ports by changing the volatile port configuration of the ACL
user module.
The default value is "Enabled".
All
means all ports will have one specific setting.
 Counter Counts the number of frames that match this ACE.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
: Click to refresh the page; any changes made locally will be undone.
: Click to clear the counters.
4.10.5 ACL Rate Limiter Configuration
Configure the rate limiter for the ACL of the switch.
The ACL Rate Limiter Configuration screen in
Figure 4-10-5 appears.
