User’s Manual of NS3550-8T-2S

82

to 126.

View Type

Indicates the view type that this entry should belong to. Possible view type are:

included

: An optional flag to indicate that this view subtree should be

included.

excluded

: An optional flag to indicate that this view subtree should be

excluded.

General, if a view entry's view type is 'excluded', it should be exist another view
entry which view type is 'included' and it's OID subtree overstep the 'excluded'
view entry.

OID Subtree

The OID defining the root of the subtree to add to the named view. The allowed
OID length is 1 to 128. The allowed string content is digital number or asterisk(*).


Buttons

: Click to add a new view entry.

: Click to save changes.

: Click to undo any changes made locally and revert to previously saved values.

4.3.4.5 SNMPv3 Access

Configure SNMPv3 accesses table on this page. The entry index keys are Group Name, Security Model and Security Level.
The SNMPv3 Access screen in

Figure 4-3-7

appears.

Figure 4-3-7:

SNMPv3 Accesses Configuration Page Screenshot

The page includes the following fields:

Object

Description

Delete

Check to delete the entry. It will be deleted during the next save.

Group Name

A string identifying the group name that this entry should belong to. The allowed
string length is 1 to 32, and the allowed content is the ASCII characters from 33
to 126.

19.

Security Model

Indicates the security model that this entry should belong to. Possible security
models are:

any

: Accepted any security model (v1|v2c|usm).

v1

: Reserved for SNMPv1.

v2c

: Reserved for SNMPv2c.

usm

: User-based Security Model (USM)

20.

Security Level

Indicates the security model that this entry should belong to. Possible security
models are:

NoAuth, NoPriv

: None authentication and none privacy.

Auth, NoPriv

: Authentication and none privacy.

Auth, Priv

: Authentication and privacy.

Read View Name

The name of the MIB view defining the MIB objects for which this request may
request the current values. The allowed string length is 1 to 32, and the allowed
content is the ASCII characters from 33 to 126.

Write View Name

The name of the MIB view defining the MIB objects for which this request may
potentially SET new values. The allowed string length is 1 to 32, and the allowed
content is the ASCII characters from 33 to 126.
