0x607C - Home position
0x6098 - Homing method
Index | Name:
0x607C | Home position
Data type: INTEGER_32
Code: C02642
Position which is set as current position during a reference search in the home position or when setting the
reference.
• Direct illustration of the Lenze code C02642 (reference position).
Setting range
(min. value | unit | max. value)
Lenze setting
-2147483647
pos unit
2147483647 0 pos unit
;
Read access ; Write access CINH PLC-STOP PDO_MAP_RX PDO_MAP_TX
Index | Name:
0x6098 | Homing method
Data type: INTEGER_8
All CiA402 homing methods are supported.
• If "0" is selected, the homing modes will be selected via the 0x55AF (Lenze code C02640) manufacturer-specific
object instead.
Selection list
(Lenze setting printed in bold)
Information
-2 Lenze cw_Trq_Lim
"Homing to limit stop"
(Lenze homing mode 14)
-1 Lenze ccw_Trq_Lim
"Homing to limit stop"
(Lenze homing mode 15)
0 Lenze homing mode
The homing is done according to the Lenze homing mode
selected in 0x55AF (Lenze code C02640)
1 Homing method 01 acc. to DS401
Homing methods according to CiA402
... Homing method ... acc. to DS401
35 DS401 homing method 35
;
Read access ; Write access CINH PLC-STOP PDO_MAP_RX PDO_MAP_TX
