9400 Technology applications | CiA402 device profile
Parameter reference
Structure of the parameter descriptions
192
L
EDS94TA11010xxxx EN 1.2 - 03/2010
5.1
Structure of the parameter descriptions
Each parameter is described in the
in the form of a table which consists of
the following three areas:
Table header
The table header contains the following general notes:
Parameter number (Cxxxxx)
Parameter name (display text in the »Engineer» and keypad)
Decimal and hexadecimal parameter index for access via bus systems
Table contents
The table contains further general explanations & notes on the parameter and the possible
settings the representation of which depends on the parameter type:
Parameters with read-only access
Table footer
The table footer contains the
.
5.1.1
Data type
The following data types are available for parameters:
Data type
Meaning
INTEGER_8
8-bit value with sign
INTEGER_16
16-bit value with sign
INTEGER_32
32-bit value with sign
INTEGER_64
64-bit value with sign
UNSIGNED_8
8-bit value without sign
UNSIGNED_16
16-bit value without sign
UNSIGNED_32
32-bit value without sign
UNSIGNED_64
64-bit value without sign
FLOATING_POINT
32-bit floating point number
VISIBLE_STRING
String of characters from printable characters
OCTET_STRING
String of characters from any characters
BITFIELD_8
8-bit value bit-coded
BITFIELD_16
16-bit value bit-coded
BITFIELD_32
32-bit value bit-coded
