C03600 | position demand value, C03601 | homing method, C03602 | brake control – Lenze E94AxHE Technology Application CiA402 Device profile User Manual
Page 211: C03603 | brake torque add, C03604 | following error reaction, C03605 | safe io state, Code, C03602, C03603, C03604

EDS94TA11010xxxx EN 1.2 - 03/2010
L
211
9400 Technology applications | CiA402 device profile
Parameter reference
Parameter list | C03600
C03600
C03601
C03602
C03603
C03604
C03605
Parameter | Name:
C03600 | Position demand value
Data type: INTEGER_32
Index: 20975
d
= 51EF
h
CiA402 object
Display range
(min. value | unit | max. value)
-2147483647
2147483647
;
Read access Write access CINH PLC STOP No transfer
Scaling factor: 1
Parameter | Name:
C03601 | Homing method
Data type: INTEGER_8
Index: 20974
d
= 51EE
h
CiA402 object
Setting range
(min. value | unit | max. value)
Lenze setting
-2
35 0
;
Read access ; Write access CINH PLC STOP No transfer
Scaling factor: 1
Parameter | Name:
C03602 | Brake control
Data type: UNSIGNED_8
Index: 20973
d
= 51ED
h
CiA402 object
Setting range
(min. value | unit | max. value)
Lenze setting
0
255 0
;
Read access ; Write access CINH PLC STOP No transfer
Scaling factor: 1
Parameter | Name:
C03603 | Brake torque add
Data type: INTEGER_32
Index: 20972
d
= 51EC
h
CiA402 object
Setting range
(min. value | unit | max. value)
Lenze setting
-2147483648
2147483647 0
;
Read access ; Write access CINH PLC STOP No transfer
Scaling factor: 1
Parameter | Name:
C03604 | Following error reaction
Data type: UNSIGNED_16
Index: 20971
d
= 51EB
h
CiA402 object
Selection list
(Lenze setting printed in bold)
0 No response
1 Fault
2 Trouble
3 Quick stop by trouble
4 Warning locked
5 Warning
6 Information
;
Read access ; Write access CINH PLC STOP No transfer
Scaling factor: 1
Parameter | Name:
C03605 | Safe IO state
Data type: UNSIGNED_8
Index: 20970
d
= 51EA
h
CiA402 object
Display range
(min. value | unit | max. value)
0
255
;
Read access Write access CINH PLC STOP No transfer
Scaling factor: 1
