9400 Technology applications | CiA402 device profile
Parameter setting & configuration
Factor group
0x607E - Polarity
0x6089 - Position notation index
0x608A - Position dimension index
Index | Name:
0x607E | Polarity
Data type: UNSIGNED_8
Mounting directions
Subindex Name
Polarity of motor
Polarity of load
Index | Name:
0x607E/1 | Polarity of motor
Data type: UNSIGNED_32
Code: C02527
Motor mounting direction
• Direct mapping of the Lenze code C02527 (motor mounting direction).
Setting range
(min. value | unit | max. value)
Lenze setting
0
1 1
;
Read access ; Write access ; CINH PLC-STOP PDO_MAP_RX PDO_MAP_TX
Index | Name:
0x607E/2 | Polarity of load
Data type: UNSIGNED_32
Code: C02529
Position encoder mounting dir.
• Direct mapping of the Lenze code C02529 (position encoder mounting direction).
Setting range
(min. value | unit | max. value)
Lenze setting
0
1 1
;
Read access ; Write access ; CINH PLC-STOP PDO_MAP_RX PDO_MAP_TX
Index | Name:
0x6089 | Position notation index
Data type: INTEGER_8
Multiplier for position values (10 exp value, decimal point)
Setting range
(min. value | unit | max. value)
Lenze setting
0
0 0
;
Read access ; Write access CINH PLC-STOP PDO_MAP_RX PDO_MAP_TX
Index | Name:
0x608A | Position dimension index
Data type: UNSIGNED_8
Unit for position values
Setting range
(min. value | unit | max. value)
Lenze setting
0
0 0
;
Read access ; Write access CINH PLC-STOP PDO_MAP_RX PDO_MAP_TX
