C03011 | counter singleerror, C03012 | counter multierror, C03013 | reset errorcounter – Lenze E94AxHE Technology Application CiA402 Device profile User Manual
Page 199: C03500 | cia402 profile, C03503 | motor type

EDS94TA11010xxxx EN 1.2 - 03/2010
L
199
9400 Technology applications | CiA402 device profile
Parameter reference
Parameter list | C03011
C03011
C03012
C03013
C03500
C03503
Parameter | Name:
C03011 | Counter SingleError
Data type: INTEGER_32
Index: 21564
d
= 543C
h
Displays the number of recognised telegram failures (single errors)
Display range
(min. value | unit | max. value)
-2147483647
2147483647
;
Read access Write access CINH PLC STOP No transfer
Scaling factor: 1
Parameter | Name:
C03012 | Counter MultiError
Data type: INTEGER_32
Index: 21563
d
= 543B
h
Displays the number of recognised telegram failures (multiple errors)
Display range
(min. value | unit | max. value)
-2147483647
2147483647
;
Read access Write access CINH PLC STOP No transfer
Scaling factor: 1
Parameter | Name:
C03013 | Reset Errorcounter
Data type: UNSIGNED_8
Index: 21562
d
= 543A
h
TRUE = Reset counter for recognised telegram failures
Selection list
(Lenze setting printed in bold)
0 FALSE
1 TRUE
;
Read access ; Write access CINH PLC STOP No transfer
Scaling factor: 1
Parameter | Name:
C03500 | CiA402 profile
Data type: UNSIGNED_32
Index: 21075
d
= 5253
h
Display range
(min. value | unit | max. value)
0
4294967295
;
Read access Write access CINH PLC STOP No transfer
Scaling factor: 1
Parameter | Name:
C03503 | Motor type
Data type: UNSIGNED_16
Index: 21072
d
= 5250
h
CiA402 object
Selection list
(Lenze setting printed in bold)
0 Non-standard motor
1 Phase modulated DC motor
2 Frequency controlled DC motor
3 PM synchronous motor
4 FC synchronous motor
5 Switched reluctance motor
6 Wound rotor induction motor
7 Squirrel cage induction motor
8 Stepper motor
9 Micro-step stepper motor
10 Sinusoidal PM BL motor
11 Trapezoidal PM BL motor
;
Read access ; Write access CINH PLC STOP No transfer
Scaling factor: 1
