Lenze E94AxHE Technology Application CiA402 Device profile - Manual (Page 207)

EDS94TA11010xxxx EN 1.2 - 03/2010
L
207
9400 Technology applications | CiA402 device profile
Parameter reference
Parameter list | C03571
C03571
C03572
C03573
C03574
C03575
C03576
Parameter | Name:
C03571 | Velocity encoder factor
Data type: UNSIGNED_32
Index: 21004
d
= 520C
h
CiA402 object 0x6094
Display range (min. value | unit | max. value)
2 2
; Read access Write access CINH PLC STOP No transfer Scaling factor: 1
Parameter | Name:
C03572 | Velocity encoder factor numerator
Data type: UNSIGNED_32
Index: 21003
d
= 520B
h
CiA402 object 0x6094.1
Setting range (min. value | unit | max. value) Lenze setting
1 1 1
; Read access ; Write access CINH PLC STOP No transfer Scaling factor: 1
Parameter | Name:
C03573 | Velocity encoder factor divisor
Data type: UNSIGNED_32
Index: 21002
d
= 520A
h
CiA402 object 0x6094.2
Setting range (min. value | unit | max. value) Lenze setting
1 1 1
; Read access ; Write access CINH PLC STOP No transfer Scaling factor: 1
Parameter | Name:
C03574 | Velocity factor1
Data type: UNSIGNED_32
Index: 21001
d
= 5209
h
CiA402 object 0x6095
Display range (min. value | unit | max. value)
2 2
; Read access Write access CINH PLC STOP No transfer Scaling factor: 1
Parameter | Name:
C03575 | Velocity factor1 numerator
Data type: UNSIGNED_32
Index: 21000
d
= 5208
h
CiA402 object 01x6095.1
Setting range (min. value | unit | max. value) Lenze setting
1 1 1
; Read access ; Write access CINH PLC STOP No transfer Scaling factor: 1
Parameter | Name:
C03576 | Velocity factor1 divisor
Data type: UNSIGNED_32
Index: 20999
d
= 5207
h
CiA402 object 0x6095.2
Setting range (min. value | unit | max. value) Lenze setting
1 1 1
; Read access ; Write access CINH PLC STOP No transfer Scaling factor: 1
