9400 Technology applications | CiA402 device profile
Parameter reference
Parameter list | C03690
218
L
EDS94TA11010xxxx EN 1.2 - 03/2010
C03690
C03691
C03700
C03701
C03706
C03707
Parameter | Name:
C03690 | Target position
Data type: INTEGER_32
Index: 20885
d
= 5195
h
CiA402 object 0x607A
Display range (min. value | unit | max. value)
-2147483647 2147483647
; Read access Write access CINH PLC STOP No transfer Scaling factor: 1
Parameter | Name:
C03691 | Offset position
Data type: INTEGER_32
Index: 20884
d
= 5194
h
CiA402 object 0x60B0
Setting range (min. value | unit | max. value) Lenze setting
-2147483648 2147483647 0
; Read access ; Write access CINH PLC STOP No transfer Scaling factor: 1
Parameter | Name:
C03700 | Touch probe function
Data type: UNSIGNED_16
Index: 20875
d
= 518B
h
CiA402 object 0x60B8
Touch probe
Setting range (min. value | unit | max. value) Lenze setting
0 65535 0
; Read access ; Write access CINH PLC STOP No transfer Scaling factor: 1
Parameter | Name:
C03701 | Touch probe function
Data type: UNSIGNED_16
Index: 20874
d
= 518A
h
CiA402 object 0x60B9
Touch probe
Display range (min. value | unit | max. value)
0 65535
; Read access Write access CINH PLC STOP No transfer Scaling factor: 1
Parameter | Name:
C03706 | Touch probe pos1 pos value
Data type: INTEGER_32
Index: 20869
d
= 5185
h
CiA402 object: 0x60BA
Touch probe
Display range (min. value | unit | max. value)
-2147483647 2147483647
; Read access Write access CINH PLC STOP No transfer Scaling factor: 1
Parameter | Name:
C03707 | Touch probe pos1 neg value
Data type: INTEGER_32
Index: 20868
d
= 5184
h
CiA402 object: 0x60BB
Touch probe
Display range (min. value | unit | max. value)
-2147483647 2147483647
; Read access Write access CINH PLC STOP No transfer Scaling factor: 1
