Chapter 67: LLDP and LLDP-MED
1028
Configuring Ports to Send Optional LLDP TLVs
This example illustrates how to configure the ports to send optional LLDP
TLVs along with the mandatory TLVs, to their neighbors. Refer to Table 95
for the list of optional LLDP TLVs.
This example configures ports 18 and 24 to send these optional TLVs,
along with the mandatory TLVs:
 port-description
 link-aggregation
 mac-phy-config
Table 97. Optional LLDP TLVs
TLV Designator Description
port-description Port description
system-name System name
system-description System description
system-capabilities System capabilities
management-address Management IP address
port-vlan Port VLAN
port-and-protocol-vlan Port and Protocol VLANs
vlan-names Names of VLANs in which the port
is a member.
protocol-ids Protocol IDs
mac-phy-config Speed and duplex mode
power-management Power via MDI capabilities
link-aggregation Link aggregation status
max-frame-size The maximum supported frame
size of the port.
