Fabric View
3–51 Web Tools Version 3.0.x/4.0.x User Guide 3–51
QuickLoop
A QuickLoop license is required to use this tab. Use the QuickLoop tab to create and
manage QuickLoops. For information on managing the QuickLoop feature separately,
see “Loop Tab” on page 5–8. The QuickLoop tab is shown in Figure 3–22.
Figure 3–22: QuickLoop tab of the AL_PA Level Zoning Menu
Clr All Select to clear the zoning database, disable the
effective configuration (if there is one), and then commit
to the switch.
Table 3–18: AL_PA Device Zone Tab Fields (Continued)
