Fabric View

3–64

Web Tools Version 3.0.x/4.0.x User Guide

Table 3–24 gives descriptions of the fields on the Fabric Assist tab.

Table 3–24: Fabric Assist Tab Fields

FA Name

Select an existing Fabric Assist name to be
modified.

Create FA

Click to create a new Fabric Assist. A dialog
displays. Enter the name of the new Fabric
Assist. All names must be unique and contain no
spaces.

Delete FA

Click to delete the Fabric Assist selected in the
FA Name field. Deleting a Fabric Assist
automatically removes it from all aliases, zones,
and zone configurations, including the
associated AL_PAs.

Rename FA

Click to edit the name of the Fabric Assist
selected in the FA Name field.

Member Selection List

This field displays a list of members available to
add to the Fabric Assist.

Add FA Host

Click to add the selected item as a host to the
Fabric Assist name Members list. Only a domain
port or a WWN can be added as a host.

Add Mem

Click to add the member selected in the Member
Selection List to the Fabric Assist name
Members list.

Remove Mem

Click to remove the selected member from the
Fabric Assist name Members list.

Search Mem

Click to search for a switch name, WWN, alias,
zone, QuickLoop, or FA Zone in the Member
Selection List based on the type of objects
displayed in that list.

Add Other

Click to add a switch/port, WWN, or a device that
currently is not part of the Fabric.

Add Other Host

Click to add other host that currently is not part
of the fabric.
