Fabric View

3–24

Web Tools Version 3.0.x/4.0.x User Guide

Table 3–9 gives descriptions of the fields on the QuickLoop tab.

Table 3–9: QuickLoop Tab Fields

QuickLoop Name

To modify an existing QuickLoop, select a QuickLoop
name.

Create Qloop

Click to create a new QuickLoop. A dialog displays in
which you can enter the name of the new QuickLoop. All
names must be unique and contain no spaces.

Delete Qloop

Click to delete the QuickLoop selected in the QuickLoop
Name field. Deleting a QuickLoop automatically removes
it from all aliases, zones, and zone configurations,
including the associated AL_PAs.

Rename Qloop

Click to edit the name of the QuickLoop selected in the
QuickLoop Name field. A dialog displays in which you can
edit the name of the QuickLoop.

Switch Selection List

A list of the switches available to add to the QuickLoop.

Search Mem

Click to search for a switch name, WWN, alias, zone, or
QuickLoop in the Switch Selection List based on the type
of objects displayed in that list.

Add Mem

Click to add the switch selected in the Switch Selection
List to the QuickLoop Members list.

Remove Mem

Click to remove the selected member from the QuickLoop
Name list.

[QuickLoop Name]
Members

A list of the members of the QuickLoop currently selected
in the QuickLoop Name field. The name of this list
depends on the name of the selected QuickLoop. If no
QuickLoop is selected, the name displays as “null
Members.”

Apply

Click to apply all changes made since the Zone
Administration View was opened, including changes
made on other tabs in the view. Changes cannot be
cancelled once they are applied.

Close

Click to cancel all changes since the changes were last
applied and to exit Zone Administration. Changes cannot
be cancelled once they are applied.

Clr All

Select to clear the zoning database, disable the effective
configuration (if there is one), and then commit to the
switch.
