Fabric View

3–108

Web Tools Version 3.0.x/4.0.x User Guide

Table 3–40 provides a description of the fields on the Alias tab.

Table 3–40: Alias Tab Fields

Alias Name

Select an existing alias to modify.

Create Alias

Click to create a new alias. A dialog displays.Enter the
name of the new alias. All names must be unique and
contain no spaces.

Delete Alias

Click to delete the alias selected in the Alias Name field.
Deleting an alias automatically removes it from all zones.

Rename Alias

Click to rename the alias selected in the Alias Name
field. A dialog displays in which you can edit the alias
name. Renaming an alias automatically renames it in all
zones.

Member Selection
List

This field displays a list of potential alias members,
including switches, ports, WWNs, and QuickLoop
AL_PAs, and Fabric Assists.

[Alias] Members

This field lists the members of the alias selected in the
Alias Name pull-down menu. The name of this list
depends on the name of the selected alias. If no alias is
selected, the name displays as “Null Members.”

< Search Mem

Click to search for a switch name, WWN, alias, zone,
QLoop, or FA Zone in the Member Selection List based
on the type of objects displayed in that list.

Add FA Host >

Click to add a Fabric Assist Host to the member list.

Add Mem >

Click to add a member from the Member Selection List to
the Alias Members list.

< Remove Mem

Click to remove the selected member from the Alias
Members list.

Add Other >

Click to add a switch/port, WWN or a device that
currently is not part of the fabric. A dialog box will display
for you to type in the host that is not a member of the
fabric.

Add Other Host >

Click to add a host that is not currently part of the fabric.

Ref Zone

Click to refresh the local zoning database copied from
the switch. This button automatically flashes red/gray if
the fabric zoning data is changed by another client.
