Fabric View

3–68

Web Tools Version 3.0.x/4.0.x User Guide

Zone Administration View V4.0.x (Optional Software)

A Zoning license and administrative privileges are required to access this view. If a
switch or device is added or removed from the network, it is necessary to save the
changes and relaunch the Zone Administration view for the changes to take effect.

NOTE: The following section is intended to describe Zoning configurations when using Web
Tools 4.0.x. For information specific to V3.0.x, see ”Zone Administration View V3.0.x (Optional
Software)” on page 3–13. F
or more detailed information about Zoning, refer to the HP
StorageWorks Zoning Version 3.0.x/4.0.x User Guide.

Accessing the Zone Administration View

1. Launch Web Tools, displaying Fabric View.

2. Click the Zone Admin icon.

For more information, see “Buttons and Icons” on page 3–4.

A prompt displays requesting User Name and Password.

3. Enter User Name and Password.

NOTE: Logging in as Root or Admin will allow you have Read and Write access. Logging in
as a User will only allow Read access.

A/D WWN

Click to add or delete a WWN to or from all the
aliases and zones defined.

Rpl WWN

Click to replace a WWN with another one in all
aliases and zones defined.

OK

Applies the changes to the switch and exits the
window.

Apply

Click to apply all changes made including changes
made on other tabs in the view. Changes cannot
be cancelled once they are applied.

Close

Click to exit the window without making any
changes to the switch.

Clr All

Select to clear the zoning database, disable the
effective configuration (if there is one), and then
commit to the switch.

Table 3–25: Config Tab Fields (Continued)
