Fabric View

3–41

Web Tools Version 3.0.x/4.0.x User Guide

3–41

Table 3–15 gives descriptions of the fields on the WWN Fabric Assist tab.

Table 3–15: WWN Fabric Assist Tab Fields

FA Name

Select an existing WWN Fabric Assist name to
modify.

Create FA

Click to create a new WWN Fabric Assist. A dialog
displays. Enter the name of the new WWN Fabric
Assist. All names must be unique and contain no
spaces.

Delete FA

Click to delete the WWN Fabric Assist selected in
the FA Name field. Deleting a WWN Fabric Assist
automatically removes it from all aliases, zones,
and zone configurations, including the associated
AL_PAs.

Rename FA

Click to edit the name of the WWN Fabric Assist
selected in the FA Name field.

Member Selection List

This field displays a list of members available to
add to the WWN Fabric Assist.

Add FA Host

Click to add the selected item as a host to the
WWN Fabric Assist name list. Only a domain port
or a WWN can be added as a host.

Add Mem

Click to add the member selected in the Member
Selection List to the WWN Fabric Assist name list.

Remove Mem

Click to remove the selected member from the
WWN Fabric Assist name list.

Search Mem

Click to search for a switch name, WWN, alias,
zone, QuickLoop, or FA Zone in the Member
Selection List based on the type of objects
displayed in that list.

[WWN Fabric Assist Name]
FA Members

A list of the members that belong to the WWN
Fabric Assist currently selected in the FA Name
field. The name of this list depends on the name of
the WWN Fabric Assist selected. If no WWN
Fabric Assist is selected, the name displays as
“null Members.”
