Introducing Web Tools

1–6

Web Tools Version 3.0.x/4.0.x User Guide

Administrative Interface, Performance View, and Port Information View. It includes
buttons that display the status of the switch fans, temperature monitors, switch info,
switch status, power supply, High Availability (for 4.0.x), and beacon.

See Figure 1–2 and Figure 1–3 for examples of Switch View. For information about
the functions that are accessible through the Switch View, see “Switch View” on
page 4–1.
